Description

Getman Mechanical Scalers are a key component of maintaining safe and productive working environments in underground operations, performing the necessary task of scaling safely and effectively through a purpose-built design philosophy.  Mechanical scaling is the safest way to bring down loose material from back and rib surfaces.

Scaler components include an operator compartment removed from the scaling area at the far rear of the machine and a secure chassis that does not require stabilizers, making any necessary emergency maneuvers possible in a single-step operation.  The optimized line of sight to the scaling area improves visibility and operational effectiveness, while the cabin is rubber-mounted onto the chassis to reduce vibration transfer to the operator.

Getman’s S3120 Mechanical Scaler has an optimal roof scaling coverage range of 3 m to 7 m (9.8 ft to 23 ft) and an optimal rib scaling coverage range from 2 m to 7 m (6.5 ft to 23 ft).  The single extension boom allows an advance over 4 m (13.1 ft) from a single setup, while the independently slewing boom allows for scaling in narrow mine sections.



Downloads

A64 Scaler S3120 Product Datasheet

Please enter an email address to receive this document.
  • This field is for validation purposes and should be left unchanged.

Scaler S3120 Drawing Sheet

Scaler Catalog
